Advances in Electric Vehicle Technologies

1.0 Introduction:

The idea to employ electric motors to drive a vehicle surfaced after the innovation of the electric motor itself. From 1897 to 1900 Electric Vehicles (EVs) become 28% of the total vehicles and was preferred over Internal Combustion Engine (ICE).  However, despite the promise of the early electric vehicles, once cheap oil was readily available and the self-starter for IC Engines had arrived, IC Engine proved a more attractive option for powering the vehicles. Another prime reason for the greater success of IC Engine was its increased specific energy compared to EV. IC Engine vehicle has longer ranges and easy to refuel.






The necessity of now shifting to EV is well known, especially the shortage of fossil fuel in the near future and the deep concern about the environment, particularly exhaust emission and noise. Good point here to highlight is EV technologist though less in number, done their bits across the globe and brought to this technology in the limelight. Being a developing technology, EVs still have many limitations that have to be overcome, to enable them to penetrate into the market. To overcome these limitations, new vehicle technologies need to be developed. Across the globe, if we see, the EV technology was growing and innovations were happening especially in Electric Propulsion (EP) and Energy Storage Systems(ESS), which are the core technology areas in EV Engineering.

If we see the scenario in India, the “National Electric Mobility Mission Plan 2020” projected by Heavy Industries Departments, Govt. India in  2012, had given the direction towards implementation of EV in India, with an ambitious plan of at least 5 to 7 million vehicles by the year 2020  and full electric vehicle by 2030. If we see the present scenario, the total EV now on Indian road is around 1.5 million. We will be able to point out multiple reasons for the shortfall. One of the reasons is definitely the lack of focus on EV technologies development in the country and their steady fast implementation so that the EV is economical and appealing to a common man.

In the aforesaid document, it is clearly emphasized the need for Research & Development (R&D) in the EV technology area. Battery, Electric Motor, Power Electronics, Battery Management System(BMS) and Powertrain System Integration are considered as the area which needs focus. It is also mentioned that the R&D initiative will be taken up as a collaborative effort between Govt-Industry and R&D agencies. Necessary funding scheme was also discussed.

This article discusses the advancement in the core areas of EV viz. Electric Propulsion and Energy Storage System across the globe and its relevance to India. Electric Propulsion comprises the Electric Motor, Electronic Controller, Power Converter, Power Transmission & Wheels. Energy Storage System (ESS) includes Battery, Ultracapacitors, Flywheel, Fuel cells and the on the board charging system. Focussed research is happening in countries like the US, France, Switzerland etc who are well aware of their limitation in sourcing and usage of special high energy materials needed for EV subsystems. India also need to take a similar step to have a major breakthrough in the EV industry that will help in bringing the price-performance gap thereby boosting demand for EV in India

2.0 Major Trends and Future Development across the globe

Following are the major areas where the EV industry focuses across the globe to make the EV technology efficient, affordable and convenient.

  • Future Electric Drives
  • Better Battery Technology
  • Better Battery charging technology
  • Ultracapacitors
  • Wireless power transfer

Electric Propulsion system is the heart of the EV and an electric motor sits right in the core of the system. Requirements for a motor EV use include high power, high torque, wide speed range, high efficiency, reliability robustness, reasonable cost, and low noise. For low power applications, permanent magnet motors and for high power applications, induction motors are now generally used. But there are other types of a motor which will be more competition for a particular power level and may be cost effective.  As the numbers of EV are going to increase in the near future, the lower cost, better efficient motor technologies will survive in the market. So the research community is seriously on the job in identifying and improving different motor technologies.

One important point to be highlighted here is the awareness of the EV industry on the selection of an automotive grade electric motor, which only will result in a reliable electric vehicle. If the motor is not properly chosen, in the long run, the particular industry will end up in calling back batches of vehicles they sold. The quality control measures need to be fully implemented and necessary testing need to be carried out to get a reliable vehicle.

Permanent magnet Brushless DC Motor (BLDC) made of NdFeB is the most opted motor right now for low power EV like 2W and 3W. It has a permanent magnet rotor and the stator is provided an alternating current from a DC source through an inverter. Though the torque decreases as speed increases,  it is a good choice for small vehicles as the rotor loss is very less and mass is low compared to other motors. But the main concern is the large fluctuating large cost of Neodymium and  Dysprosium (added to increase the high-temperature coercivity of the magnets above  100 °C)  as well as its dependence on import.

40% is the PM material cost in the motor and China is the major source for NdFeB magnets. China decreased rare-earth material production by 40% in 2010. In this context, right from 2010 onwards, countries like the US are seriously focussing their research to make non-rare earth magnet motors and permanent magnet free motors. They had succeeded in this efforts and now motors having almost same energy capacity as that of rare earth counterpart is now developed and are going for commercialization

Companies like Tesla, Toyota, and GM were already started using induction motors, but it can not be operated directly from utility power, need an inverter. Its speed control is difficult and starting torque is less. Still because of its simple construction, for high power EV application, it will be the choice for some more time. In India, the three EV models, Mahindra e2O, Tata Tigor, and Mahindra e-Verito uses induction motors.

2.1 Future Electric Drive

As competition picks up in EV domain, the technologies essentially grow to give better efficiency at low cost. There are different motor technologies which are now researched and are expected to be used in EV. Some of these technologies are already there and need only optimize the parameters. There are few new configurations evolved basically derived from the existing one with performance optimization.

2.1.1 High Power Density Ferrite PM Motor

Given below the comparison of the energy density of Permanent Magnets (PMs), which directly decide the size of the motor. Obviously, the lowest energy product is ferrite, but its demagnetisation characteristic is linear. So it will resist the demagnetisation under load condition. The task taken up by the researchers is optimization of motor design, improvement of the material properties etc so that the specific power similar to that of rare earth magnet motors are achieved.



Magnetic energy comparison of different permanent magnets
Fig.1 Magnetic energy comparison of different permanent magnets

Novel motor designs need to be developed and optimized using high-performance computing techniques. Findings from fundamental magnetic materials research are to be incorporated into new modeling tools to improve accuracy, and this has been greatly facilitated with parallelized computing.

To improve motor modeling accuracy and complement new materials and processing developments, fundamental research needs to be conducted to study the phenomena behind magnetization and loss characteristics of soft magnetic materials in electric motors, details that are still not fully quantified or understood in the scientific community. For example, residual stresses or induced stresses incurred during manufacturing or motor operation have a considerable impact on losses and permeability.

Additionally, temperature, pulse width modulation excitation, and other factors impact the magnetic properties in a way that is not considered or modeled with conventional finite element analysis (FEA) tools. These studies supported the development of high fidelity models and modeling tools, which are particularly important as high-performance computing is used in the optimization of detailed geometric features to achieve high power density, specific power, efficiency, and cost-effectiveness.

In addition to novel motor and controls development, the development and use of new materials and materials processing techniques need to be carried out to improve magnetization and/or efficiency characteristics of soft magnetic materials (e.g., electrical steel). On the material side, one major development is the increase in silicon content in soft magnetic steel to 6% can reduce the losses by 35%. But the material becomes brittle. To make it ductile new process development need to be carried out. ( Reference of the development discussed in this section was given in “FY 2016 Annual Progress report for Electric Drive technology Program, Office of energy efficiency & Renewable energy, US Dept of Commerce, 2017)






2.1.2 Motor Design and Power Density Optimization of a Ferrite Interior Permanent Magnet

Spoke-type ferrite Interior Permanent Magnets (IPMs) have received attention in recent years due to the push for reduced RE content in PMs. The spoke topology refers to a method of arranging the magnets on the rotor, so the flux is produced and concentrated in the tangential direction before crossing the air gap to the stator. This topology allows a great increase in the magnet mass on the rotor and, because of this, is promising for ferrite-based machines intended to replace those using NdFeB magnets.

However, most ferrite-based spoke IPMs explored in the literature use expensive techniques to reduce leakage flux (e.g., keyed beryllium hubs), result in limited speed ratings (less than 8,000 rpm, free rotor pole pieces with axial support posts), use more expensive high strength steel, or have not been optimized over a wide variety of parameters. Optimizing a spoke-type machine to achieve an understanding of the achievable power density of ferrite-based IPMs is being researched.

Fig.2 Magnet arrangement in Spoke type ferrite PM machine
Fig.2 Magnet arrangement in Spoke type ferrite PM machine

2.1.3 Permanent Magnet Synchronous Motor (PMSM)

The permanent magnet synchronous motor is cross between an induction motor and brushless DC motor. Like a brushless DC motor, it has a permanent magnet rotor and windings on the stator. However, the stator structure with windings constructed to produce a sinusoidal flux density in the air gap of the machine resembles that of an induction motor. Permanent magnet synchronous motors’ power density is higher than induction motors with the same ratings since there is no stator power dedicated to magnetic field production. Today, these motors are designed to be more powerful while also having a lower mass and lower moment of inertia. The speed control is usually done by field oriented control

It is capable of being operated at a range of speed without the need of any gear system. Capable of delivering high torque at all speed ranges and now used in at least 26 vehicles. Nissan Leaf and Toyota Prius are examples.

2.1.4. Motors With reconfigurable winding

Electric machine with reconfigurable winding, also known as switchable winding, is any drive system which is able to change, by means of electronic switches between two or more impedance modes as viewed at motor terminal. Most of the reconfigurable winding was developed for induction machine or surface mounted permanent magnet machines. This scheme can replace mechanical gear box.

2.1.5 Synchronous Reluctance motor (SynRM)

A synchronous reluctance motor runs at a synchronous speed while combining the advantage of both Permanent magnet and induction motors. They are robust and fault tolerant like induction motor and efficient and small like PM motor and do not have drawbacks of PM systems. The problem with SynRM can be associated with controllability, manufacturing and low power factor which hinder the use in EV. The main area of concern was rotor design and research is going on to increase the saliency which gives higher power factor. It can be achieved by axially and transversally laminated rotor structures

2.1.6  PM assisted Synchronous Reluctance motor.

Greater power factors can be achieved from Syn RM by integrating some PM in the rotor creating a PM assisted Synchronous Reluctance Motor. PM is added in the right amount to the core of the rotor increases the efficiency. With proper efficiency optimization technique, this motor can have performance similar to a permanent magnet machine, same time free from demagnetizing problem observed in Permanent magnet machine. In BMW i3 EV it was used.

2.1.7 Switched Reluctance Motors. (SRM)

Known as a doubly salient (because of having salient poles both in stator and rotor) are synchronous motor driven by unipolar inverter-generated current. They demonstrate simple and robust mechanical construction, low cost, high speed, less chance of hazards, inherent long constant power range and high power density. But on the downside, they are very noisy because of variable torque nature, low efficiency and larger size compared to PM motors. Advanced design techniques are used to resolve the above issues. Because of the high cost of permanent magnets, the interest in SRM is growing now.






3.0  Future Battery Technology

Batteries have been the major energy source for EV, different battery technologies have been invented and adopted. This process is still going on to attain the desired performance goal. Following are some of the desired performance parameter set by U.S. Advanced Battery Consortium (USABC) as a long term goal.

Parameters Set goal
Specific Energy (Wh/kg) 200
Specific Power(80% DoD)  (W/kg) 600



Known and prevailing battery technology for EV  is Lead acid, Nickel Metal Hydroxide, and Lithium-ion. Limitation of Lead-acid and Nickel Metal hydroxide batteries are Low specific energy and limited life cycles. Of which the advances made in the last few years is Lithium-ion batteries. Lithium-ion batteries are the most popular one now and are definitely going to stay. The improvements in its specific energy from 150Wh/kg to 200Wh/kg is the research activity happening. There are about 6 technologies in Lithium-Ion Battery (LIB) and out of that preferred one for  EV is Lithium Nickel Manganese Cobalt Oxide (NMC) and Lithium Nickel Cobalt Aluminum Oxide (NCA).

Two new types of Li-Ion battery now coming up is  Lithium–Sulfur batteries promise the higher performance-to-weight ratio and aqueous Lithium-ion batteries which have fewer potential safety hazards due to their use of non-flammable electrolytes.

3.1 Metal-air batteries

Presently specific energy of Li-ion battery is 100-200Wh/kg. Improving the energy density will reduce the material requirement and hence the cost. Present cost is $200 per kWh and it aims to reduce it to $ 100 per kWh in the future. But there is a limit up to which the energy density can be increased. In this scenario, an alternate energy storage system is thought of.

3.1.1. Lithium-Air battery

Lithium-air provides an exciting new frontier because this battery promises to store far more energy than is possible with current lithium-ion technologies. Scientists borrow the idea from zinc-air and the fuel cell in making the battery “breathe” air. The battery uses a catalytic air cathode that supplies oxygen, an electrolyte, and a lithium anode.

The theoretical specific energy of lithium-air is 13000Wh/kg. If these energies could indeed be delivered, metal-air, as the battery is also known, would be on par with gasoline. But even if the end product were only one-quarter of the theoretical energy density, the electric motor with its better than 90 percent efficiency would make up for its lower capacity against the ICE with a thermal efficiency of only 25–30 percent.

Li-air was proposed in the 1970s and gained renewed interest in the late 2000s, in part because of advancements in material science and the endeavor to find a better battery for the electric power train. Depending on the materials used, lithium-air produces voltages of between 1.7 and 3.2V/cell. IBM, MIT, University of California and other research centers are developing the technology.

As with other air-breathing batteries, the specific power may be low, especially at cold temperatures. Air purity is also said to be a challenge as the air we breathe in our cities is not clean enough for lithium-air and would need to be filtered. For all we know, the battery may end up with compressors, pumps, and filters resembling a fuel cell, consuming 30 percent of its produced energy for auxiliary support to stay alive.

Another problem is the sudden death syndrome. Lithium and oxygen form lithium peroxide films that produce a barrier, which prevents electron movement and results in an abrupt reduction in the battery’s storage capacity. Scientists are experimenting with additives to prevent film formation. The cycle life will also need to improve; lab tests currently produce only 50 cycles.






3.1.2 Aluminium-air battery

On the other hand, Al-air batteries are in their infancy and have gained much attention due to their many practical advantages, such as high energy density and theoretical voltage, safety, and abundance of raw materials. The Al-air battery has a high theoretical voltage (2.7 V) and energy density (8.1 kWh/kg), far surpassing that of state-of-the-art LIBs. The basic structure of a primary Al-air battery, which is composed of an aluminum anode, an air cathode, and a suitable electrolyte, typically consisting of sodium hydroxide (NaOH), potassium hydroxide (KOH) or sodium chloride (NaCl) solutions, is shown in Fig-3

Fig.3 Metal-Air Battery Schematic
Fig.3 Metal-Air Battery Schematic

As pure aluminum is unstable when used as an anode for Al-air batteries, the most common method to prolonging the battery operation time and decreasing the corrosion rate is through the use of Al alloys. A considerable number of alloying elements such as Ga, In, Sn, Zn, Bi, Mn, and Mg have been adopted. The outstanding performance of Al alloys in Al-air batteries can be attributed to the comprehensive effect of each individual alloying component. The air cathode is one of the essential components of an Al-air battery, which is generally composed of a gas diffusion layer, current collector, and catalytic active layer. The gas diffusion layer is composed of a carbon material and a hydrophobic binder such as polytetrafluoroethylene (PTFE), making the diffusion layer permeable only to air and preventing the permeation of water. Current collectors are typically made of a Ni metal mesh which can be connected to the external circuit and enhance the electron transfer processes.

The research team has achieved energy density up to 1000 Wh/kg. These battery chemistries are facing a series of problems such as the corrosion of Al metals, high self-discharge rate, sluggish discharge kinetics, lack of rechargeability, and short shelf life. Therefore, critical research should be directed to overcoming a large amount of scientific and technical challenges for metal-air batteries before these promising energy storage devices are put into effect. Spain had achieved good progress in the aluminum-air battery. This now treated as the future battery technology for India, as this technology do not depend on special materials and have a substantial range and will cost less. An industry-academia research ecosystem focus on a product-oriented indigenous development programme in a big way is the need of the hour to commercialize this technology in India. Central Government cabinet decision on March 07, 2019 for the creation of Phased Manufacturing Programme (PMP) by the “going to be set up” National Mission on Transformative Mobility and Battery Storage will be really a morale booster for those who are interested in developing Aluminium-air battery in the country.

4.0  Ultracapacitors

Ultracapacitors (UCs) have two electrodes separated by an ion-enriched liquid dielectric. When a potential is applied, the positive electrode attracts the negative ions and negative electrode gathers the positive ones The charge gets physically stored on electrodes this way and provide a considerable power density. EVs go through the start/stop conditions quite a lot, especially in an urban driving situation, as well as conditions like hill climb, normally demand large current from the battery. Peak power for a high-performance electric vehicle may go up to 16 times. UC fit in perfectly for such an application. A combination of battery-UC system negates each other shortcomings and provide an efficient and reliable energy system.

5.0  Fuel Cells (FC)

Fuel cells generate electricity by electrochemical reaction. An FC has an Anode, Cathode, and electrolyte. Fuel and oxygen are introduced in the cell. Fuel gets oxidized in the anode and produces an electron. The ions created to travel through the electrolyte and react with the reactant introduced at a cathode. Hydrogen is used as the fuel, as it has high energy density and exhaust is only water. Toyota Mirai uses FC. China is going in a big way to induct FC

6.0 Wireless Charging

Wireless charging or Wireless Power Transfer (WPT) does not require the plugs and cables required in the wired charging system. Research by industries and universities brought it to the level of induction in EV. There are about 6 technologies were attempted across the globe. They are a) Inductive Power Transfer(IPT), Capacitive Power Transfer (CPT), Permanent Magnet Coupling Power Transfer(PMPT), Resonant Inductive Power Transfer(RIPT), On-Line Inductive Power Transfer(OLPT) and Resonant antennae Power Transfer(RAPT).  RIPT and OLPT appear to be more promising, but their infrastructure did not allow them to be a viable solution. Frequencies for these technologies range from 10kHz to 500kHz. Presently in some country, it is used as delta chargers of smaller capacity.

7.0 Other Technologies

  1. Inverter technologies that incorporate advanced wide bandgap (WBG) semiconductor devices to achieve higher efficiency while accommodating higher-temperature environments and delivering higher reliability. SiC MOSFET can significantly reduce inverter switching losses and have the potential to replace the Si IGBT for improved drive system efficiency and reliability with a reduction in power inverter weight and size.
  2. Converter concepts that leverage higher-switching-frequency semiconductors, nanocomposite magnetics, higher-temperature capacitors, and novel packaging techniques that integrate more functionality into applications offering reduced size, weight, and cost
  3. New onboard battery charging electronics that build from advances in converter architectures for decreased cost and size
  4. More compact and higher-performing thermal controls achieved through novel   thermal materials and innovative packaging technologies

8.0  Conclusion

The EV subsystems viz. Electric Propulsion and Energy Storage Systems are in the crossroads now, as these systems play a very vital role in making the EV popular and adoption by the public. To make it more user-friendly, especially during the long journey and tough roads, a clear focus on the improvement in EV technology is really required. Dedicated teams are working in abroad and whenever possible, the developed technologies are being commercialized. Not much focus is given in India, for the development of new EV technologies. Limitation in sourcing special materials such as lithium, rare earth materials etc are known, and the focus on the development of new technologies which minimize the use of special materials is the need of the hour.




Another important area where the focus required is on the quality and reliability of the components now procured from China for the integration of EV. Good amount of quality check is needed on the component level and how far it is possible for China to make a component is a perplexing question. This point also emphasized the need for developing indigenous components for the EV industry.

Across globe commercialization of high efficient electric drives and metal-air batteries are focussed now. It will enable EV technology to compete with IC engines. Improved ultracapacitors and safe wireless charging stations are expected to be in the market in another 4 to 5 years time frame. Fuel cell technology is matured, and some countries are focussing on the commercialization and induction in EV. New ways of recovering from a vehicle may appear. Good year have demonstrated a tire that can harvest energy from the heat generated there using thermo-piezoelectric material. There are also chances of solar-powered vehicles, being commercialized.
